About this Tutorial

This course is intended for first time users of this softwarest. Self-taught users can also profit from the structure to consolidate essential concepts. There is a lot to explain while we are modeling a Architectural Project from plans, from its pure base through gaining more detail.

Skill level and duration

Level: First Time Users

Duration: A couple of hours tops!

In this tutorial you will learn

  1. Rhino > 3D Print

  2. Rhino > Twinmotion

  3. Rhino > ArchiCAD

  4. ArchiCAD > 3D Print

  5. ArchiCAD > Twinmotion

  6. Print Display

  7. Isolate / Zoom Selected

  8. White Model Perspective and Section

The materials you will need

  1. Your laptop with internet connection to download and Install Software during the course.

Tutorial content

• 8 Videos

• Full Tutorial Script

• File to excersise de skill

Why take this tutorial

Learn simple Flash Skills that will be useful in the path of learning how to use Rhino 3D and ArchiCAD with me!
Let me teach you basic skills of the softwares for you to be ready to solve some trouble you will get while learning.




1. Rhino to 3D Print

1.1. ShowEdges/MatchMeshEdges

  1. Start Command ShowEdges to check that the mesh is closed.

  2. If not check start command MachMeshEdges to seal little gaps.

  3. If you want to learn more ways of repairing Mesh you can revise Ri-xW1a Model in Rhino for Complete Beginners chapter 5: Watertight Meshes.

1.2. Export STL

  1. Copy the final Object.

  2. Isolate the Volume.

  3. Start the Scale command.

    • Enter the intended scale: 1/200

  4. Start the Scale command.

    • Mutiply by 1000.

  5. Start command Export.

  6. Select STL Stereolithography.

  7. Adjust Tolerances by Checking in the Preview.

  8. Name corresponding to the Scale.


2. Rhino to Twinmotion

2.1. Download Plugin

  1. Download the Plugin searching for Rhino Twinmotion Plugin.

  2. Download in the Direct Link for Rhino button.

2.2. Synchronize

  1. Open Rhino.

  2. Go to Twinmotion 2020 > Synchronize

  3. Open in Twinmotion as New Project.

  4. Close the Welcome Window.

  5. You have opened your file in Twinmotion.

  6. You can upload the file by saving in Rhino.


6. Print Display

6.1. Print Display

  • If you want to see the True Line Weight of the lines you have drawn in Layout

  1. Go to the Layout or start command Layout.

  2. Start command PrintDisplay.

  3. You can see how the colors have change and you can see the line weight.


7. Isolate / Zoom Selected

7.1. Isolate

  1. If you want to Isolate a surface or curve select it.

  2. Then start command Isolate.

7.2. Zoom Selected

  1. Sometimes the Model gets messy because of the quantity of the objects, if you want to based your rotation and to get a zoom that frames one special object; select the object.

  2. Be in the Perspective View.

  3. Select the Model you want to center.

  4. Start command Zoom Select.

  5. The selected object will be framed in the window and if you rotate the center of the rotation is the same object.

7.3. Show

  1. If you want to come back to see all the project start command: Unisolate.

  2. If that doesn’t work, start command Show.


8. White Model Perspective and Section

8.1. Clipping Plane

  1. Start command ClippingPlane.

  2. Set its configuration to Vertical.

  3. Make sure Perspective is checked.

8.2. Orient Camera to Surface

  1. Start command OrientCameratoSrf.

  2. Select the surface where you want to orient the camera.

  3. Be sure the arrow of the command points to the direction where you are located if not, select Flip.

  4. You can zoom or pan to adjust the position of the view.

  5. Set 3D View to Rendered.

8.3. Preferences

  1. Go to Preferences > Display Modes > Rendered.

    • You can find it in Windows in the Options command.

  2. Go to Objects tab > Clipping Plane Objects, and adjust the following settings:

    • Show Fills: Check

    • Color usage: Solid Color

    • Show Edges: Uncheck

    • Shaded selected plane: Check

    • Color Usage: Plane’s Color

    • Transparency: 95%

    • Clip Selection Highlight: Check

  3. Start command ViewCapture.

  4. Select the view where you want to take the capture.

  5. Pick the location file and format.
